Name: | Heat Jacket Gate Valve | Connection: | RF Flange |
---|---|---|---|
Standard: | EN1984/API600 | Pressure: | 150LB,300LB,600LB,900LB,1500LB,2500LB |
Power: | Manual,Pneumatic,Solenoid,Electrical Actuated | Temperature Of Media: | Medium Temperature,Normal Temperature,High Temperature,-65°F To 450°F (-54℃ To 232℃) |
Size: | 2"-48",DN50-DN1200 |
En1984 Heating Jacket Gate Valve DN50 PN25 Wcb Handwheel Bolted Bonnet Gate Valve Flex Wedge Gate Valve
Applicable Standards:
Gate Valve:API600
Steel Valves:ASME B16.34
Face to face:ASME B16.10
End Flanges:ASME B16.5/ASME B16.47
Butt Welding ends :ASME B16.25
Inspection and test :API 598
Operated: Hand wheel
Material: A216 WCB
Size Range: 2"~48"
Pressure Rating: ASME CL, 150, 300, 600, 900, 1500, 2500
Temperature Range: -29℃~429℃
Design Description:
- Outside Screw and Yoke
- Bolted Bonnet and Pressure Seal
- Flexible and solid wedge, fully guided
- Welding seat rings or Renewable seat rings
- Rising stem and non-rising stem
- Available with gear operator
- Flange Ends & Buttwelding Ends
- Low torque design, smooth surface stem.
Brand | VERVO |
Structure | Gate |
Valve Material | Vervo provide cast steel, stainless steel, special alloy, CI, DI etc |
Valve Type | Vervo Produce Gate Valve |
Valve Test | 100% quantity tested before delivery |
Valve Guarantee | 18 months after shipments and 12 months after installed |
Valve Structure | Wedge Gate Valve |
Valve Delivery | 15 - 30 days |
Valve Sample | Sample Available by Didtek Valve |
Valve Color | Customer request |
Valve Packing | Plywood Case for Gate Valve |
MOQ | 1 Set |
Valve Certificate | API6D/CE/ISO9001/ISO14001 |
Place of Origin | Zhejiang, China (Mainland) |
Delivery Detail: | Shipped in 15-30 days after payment |
Port | Shanghai Or Ningbo |
Payment Terms | L/C,D/A,D/P,T/T, Western Union |
Application & Function:
Vervo Cast steel Gate valves are primarily used for stop valves fully opened or fully closed. They are not normally considered for throttling purposes, but more for slurries, viscous fluids, etc. Gate valves are characterized by a traveling wedge, which is moved with the operation of the stem nut. The wedge travels perpendicular to the direction of the flow. Gate valves usually have a minimum pressure drop when fully open, provide tight shut-off when fully closed, and remain relatively free of contamination buildup.
Accessories:
Accessories such as gear operators, actuators, bypasses, locking devices, chain wheels, extended stems and bonnets for cryogenic service and many others are available to meet the customers’ requirements.
FAQ
1/Do you have any Certification ?
Yes we have ISO9001-2015 and CE/PED according to Directive 2014/68/EU,fire safe certificate,ISO15848-1
2/Can we visit your factory?
Sure, we welcome you to visit our factory , check our production lines and know more about our strength and quality.
3/Do you have quality control system?
Yes, we have ISO/PED certifications and our own quality control laboratory.
4/Can you arrange the shipment for us?
Yes, we have designated sea freight and railway freight forwarders with decades of experiences and we get the best price with earliest vessel and professional service.
5/Can I get some samples?
We are glad to provide free samples to you, but the express fee will be on your charge.
6/What is your after-sale service?
We provide after-sale service and offer 100% guarantee on our products.
7/What is your main products?
Valve, and in order to meet different needs, we expanded our business, we also do sanitary type products.
8/Are you trading company or manufacturer
We are factory, and welcome to visit our factory
9/What is your MOQ
No MOQ, As your request .Normal size and material we have stock
