Flexible Wedge Gate Valves Solid Wedge Bolted Bonnet Welded Bonnet Design

Basic Information
Place of Origin: LISHUI,ZHEJIANG
Brand Name: VERVO
Certification: API/CE/ISO
Model Number: Z41Y-150LB-DN50
Minimum Order Quantity: 10
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 1 week
Payment Terms: L/C, T/T, Western Union, D/A
Supply Ability: 40000pcs/month
Name: 48 Inch Casting Steel Metal Seated Gate Valve Connection: RF Flange,Butt Welding
Standard: API6D/API600/DIN/API603 Pressure: 150 To Class 2500
Power: Manual,Pneumatic,Solenoid,Electrical Actuated Temperature Of Media: Medium Temperature,Normal Temperature,High Temperature,-65°F To 450°F (-54℃ To 232℃)
Size: NPS 2 To NPS 48
High Light:

Flexible Wedge Gate Valves

,

Welded Bonnet Design Gate Valves

,

Bolted Bonnet Gate Valves

Gate Valve

VERVO gate valves are offered in flexible wedge, solid wedge, bolted bonnet and welded bonnet design in a wide range of carbon, stainless steel, duplex stainless steel, alloy and other special materials. VERVO gate valves are manufactured according to API 600 Design.

PRODUCT RANGE

Sizes NPS 2 to NPS 48

Class 150 to Class 2500

MATERIALS

Available in Casting (A216 WCB, WC6, WC9, A352 LCB, A351 CF8, CF8M, CF3, CF3M, A995 4A, A995 5A, A995 6A), Alloy 20, Monel, Inconel, Hastelloy
DESIGN FEATURES
Full or Reduced Bore

RF, RTJ, or BW

Outside Screw & Yoke (OS&Y), rising stem

Bolted Bonnet or Pressure Seal Bonnet

Flexible or Solid Wedge

Renewable seat rings

DESIGN STANDARD

Design & manufacture according to API 600, API 603, ASME B16.34

Face-to-face according to ASME B16.10

End Connection according to ASME B16.5 (RF & RTJ), ASME B16.25 (BW)

Test & inspection according to API 598

Also available per NACE MR-0175, NACE MR-0103, ISO 15848, API624



Keywords of VERVO gate valves are offered in flexible wedge, solid wedge, bolted bonnet and welded bonnet design in a wide range of carbon, stainless steel, duplex stainless steel, alloy and other special materials.

Flexible Wedge Gate Valves Solid Wedge Bolted Bonnet Welded Bonnet Design 0

48Inch Gate Valve,API 600 Gate Valve, WCB Gate Valve, 48 Inch Gate Valve, PN6 WCB Gate Valve, Handwheel Gate Valve, Rf Flanged Gate Valve, Full Bore Gate Valve, Cast Steel Gate Valve, A216 WCB Gate Valve,LCC Gate Valve,CF8 Gate Valve,CF8M Gate Valve, 4A Gate Valve, 5A Gate Valve,ASME B16.34 Gate Valve,Flexible Wedge Gate Valve,DN1200 Gate Valve,1200mm Casting Steel A216 WCB Gate Valve
