DN25 1 Piece Type Ball Valve 25mm Ball Valve Floating Ball Valve Low Pressure Stainless Steel One Piece Ball Valve

DN25 1 Piece Type Ball Valve 25mm Ball Valve Floating Ball Valve Low Pressure Stainless Steel One Piece Ball Valve
DN25 1 Piece Type Ball Valve 25mm Ball Valve Floating Ball Valve Low Pressure Stainless Steel One Piece Ball Valve
Basic Information
Place of Origin: LISHUI,ZHEJIANG
Brand Name: VERVO
Certification: API/ISO/CE
Model Number: Q11F-DN25-1000PSI
Minimum Order Quantity: 1
Packaging Details: plywood case
Delivery Time: 30
Payment Terms: T/T, L/C, D/P, Western Union
Supply Ability: 400000
Contact Now
Design Standard: API608 Body Material:: Stainless Steel
Nominal Diameter: 0.5 Inch 1/2'' Pressure: 1000psi
End Connection.: Thread/bspt/npt Face To Face: Factory Standard
Test And Inspection: API 598

DN25 1 Piece Type Ball Valve 25mm Ball Valve Floating Ball Valve Low Pressure Stainless Steel One Piece Ball Valve



1/4" - 4" stainless steel 1 Piece Ball valve

DN25 1 Piece Type Ball Valve 25mm Ball Valve Floating Ball Valve Low Pressure Stainless Steel One Piece Ball Valve 0

The One Piece Ball valve as the name suggests is made out of one body piece unlike the 2 and 3 piece. This means the valve cannot be taken apart for cleaning. The advantage is that the valve will be low cost and robust. As a result of the valve body being one piece is that a smaller ball has to be used leading to a reduced port, more commonly called a reduced bore. This means that flow is reduced through the valve, since the ball bore is one size smaller than the pipe size.
* Threaded Ports FNPT by FNPT for standard Pipe Connection
* Reduced/Standard Port Ball Valve
* Stem is Blow Out Proof
* Pressure Rating 1000 PSI, Suitable for Standard Uses
* PTFE Seat and Seal, suitable for High Heat and Chemical Applications
* Sizes Start from 1/2" up to 2

A One piece ball valve is known for its low cost and Robust design. Like our other threaded ball valves, the 1 piece comes with female NPT threads on both ports. Commonly used in standard applications where a study valve is required and a reduced flow is not important to the application. Our 1-piece valves are made with quality grade 316 stainless steel, designed with a reduced port,pressure rated at 1000 PSI WOG (Water, Oil, Gas).
Dimention
DN25 1 Piece Type Ball Valve 25mm Ball Valve Floating Ball Valve Low Pressure Stainless Steel One Piece Ball Valve 1
SIZE
фd
L
H
W
N.M
KGS
1/4''
DN6
5
40
32
68
12
0.07
3/8"
DN10
7
45
33
68
12
0.13
1/2"
DN15
9
56
42
95
13
0.17
3/4"
DN20
12.5
59
45
95
20
0.25
1"
DN25
15
71
48
95
38
0.42
1-1/4"
DN32
20
76
58
106
50
0.68
1-1/2"
DN40
25
84
67
128
72
0.85
2"
DN50
32
99
74
130
90
1.39
2-1/2"
DN65
38
110
85
170
360
1.98
3"
DN80
50
132
85
170
600
3.6
4"
DN100
64
180
121.5
225
950
7.47



Keywords of DN25 1 Piece Type Ball Valve 25mm Ball Valve Floating Ball Valve Low Pressure Stainless Steel One Piece Ball Valve

DN25 1 Piece Type Ball Valve 25mm Ball Valve Floating Ball Valve Low Pressure Stainless Steel One Piece Ball Valve 2

Casting Steel Floating Ball Valve, Floating Ball Valve, 1000PSI Ball Valve, 1 Inch Ball Valve, API608 Ball Valve,One Piece Ball Valve,Soft Seated Ball Valve,1 Piece Ball Valve
