DN20 Grooved Connection Ball Valve Stainless Steel Floating Ball Valve Two Piece Ball Valve 2 Piece Type Soft Seat

Basic Information
Place of Origin: LISHUI,ZHEJIANG
Brand Name: VERVO
Certification: API/ISO/CE
Model Number: Q61F-DN20-300LB
Minimum Order Quantity: 1
Packaging Details: plywood case
Delivery Time: 30
Payment Terms: T/T, L/C, D/P, Western Union
Supply Ability: 400000
Design Standard: API608 Body Material:: Stainless Steel
Nominal Diameter: 3/4 Inch,DN20 Pressure: CL300
End Connection.: Grooved Face To Face: Factory Standard
Test And Inspection: API 598

DN20 Grooved Connection Ball Valve Stainless Steel Floating Ball Valve Two Piece Ball Valve 2 Piece Type Soft Seat



Function Description:

DN20 Grooved Connection Ball Valve Stainless Steel Floating Ball Valve Two Piece Ball Valve 2 Piece Type Soft Seat 0
Ball valve is a form of quarter-turn valve which uses a hollow, perforated and pivoting ball (called a "floating ball") to control flow through it. It is open when the ball's hole is in line with the flow and closed when it is pivoted 90-degrees by the valve handle. The handle lies flat in alignment with the flow when open, and is perpendicular to it when closed, making for easy visual confirmation of the valve's status.
Ball valves are durable, performing well after many cycles, and reliable, closing securely even after long periods of disuse. These qualities make them an excellent choice for shutoff applications, where they are often preferred to gate and globe valves, but they lack their fine control in throttling applications.

Application:

DN20 Grooved Connection Ball Valve Stainless Steel Floating Ball Valve Two Piece Ball Valve 2 Piece Type Soft Seat 1
Applicable Temperature: -20ºC ~ 150 ºC

Main Materials: WCB/CF8/CF8M/CF3/CF3M

Applicable Medium: Water / Oil / Gas / Causticity Medium

Pressure Rating: 1000WOG/2000WOG

Size Range: 1/4" ~ 4"(DN8-DN100)



Material
Stainless steel 304/ 304L/316/316L/201
Standard
Thread:BSPT(ISO 7/1),NPT(ASME B16.3)

Dimension:ISO 49,DIN 2950,EN10242
Physical Property
Tensile strength>=350Mpa,Elongation>=10%,Hardness<=150HB
Testing Pressure
500PSI
Working Pressure
300PSI
Model
Fittings:Elbow,Tees,Crosses,Bends,Unions,Bushing,Lateral Braches,Sockets,Nipples
Valve: Ball valve,Gate Valve,Check valve,globe valve
Connection
Male,Female,Push-fit,compression
Shape
Equal,Reducing,2pcs,3pcs
Certificate
ISO9001,CSA,NSF,CE,CUpc
Application
Suitable for fire piping system,air,oil,water supply

Buyer's drawing or designs are available
Package
Cartons without pallet

Cartons with pallet

Double woven bags

Or as buyer's requirements
Delivery Details
According to the quantities and specifications of each order

Normal delivery times is from 30 to 45 days after receiving the deposit



DN20 Grooved Connection Ball Valve Stainless Steel Floating Ball Valve Two Piece Ball Valve 2 Piece Type Soft Seat 2

RFQ

DN20 Grooved Connection Ball Valve Stainless Steel Floating Ball Valve Two Piece Ball Valve 2 Piece Type Soft Seat 3

1/Do you have any Certification ?

Yes we have ISO9001-2015 and CE/PED according to Directive 2014/68/EU,fire safe certificate,ISO15848-1

2/Can we visit your factory?

Sure, we welcome you to visit our factory , check our production lines and know more about our strength and quality.

3/Do you have quality control system?

Yes, we have ISO/PED certifications and our own quality control laboratory.

4/Can you arrange the shipment for us?

Yes, we have designated sea freight and railway freight forwarders with decades of experiences and we get the best price with earliest vessel and professional service.

5/Can I get some samples?

We are glad to provide free samples to you, but the express fee will be on your charge.

6/What is your after-sale service?

We provide after-sale service and offer 100% guarantee on our products.

7/What is your main products?

Valve, and in order to meet different needs, we expanded our business, we also do sanitary type products.

8/Are you trading company or manufacturer

We are factory, and welcome to visit our factory

9/What is your MOQ

No MOQ, As your request .Normal size and material we have stock



Keywords of DN20 Grooved Connection Ball Valve Stainless Steel Floating Ball Valve Two Piece Ball Valve 2 Piece Type Soft Seat

DN20 Grooved Connection Ball Valve Stainless Steel Floating Ball Valve Two Piece Ball Valve 2 Piece Type Soft Seat 4

DN20 Ball Valve,SS Ball Valve,2 Piece Ball Valve,Soft Seal Ball Valve,Three Piece Ball Valve,Casting steel Stainless Steel Ball Valve,Metal to Metal Seat Ball Valve



DN20 Grooved Connection Ball Valve Stainless Steel Floating Ball Valve Two Piece Ball Valve 2 Piece Type Soft Seat 6
