1/2 Inch Socket Welded Solid Wedge Gate Valve 800 LB Metal Seat Asme B1.20.1

1/2 Inch Socket Welded Solid Wedge Gate Valve 800 LB Metal Seat Asme B1.20.1
1/2 Inch Socket Welded Solid Wedge Gate Valve 800 LB Metal Seat Asme B1.20.1 1/2 Inch Socket Welded Solid Wedge Gate Valve 800 LB Metal Seat Asme B1.20.1 1/2 Inch Socket Welded Solid Wedge Gate Valve 800 LB Metal Seat Asme B1.20.1 1/2 Inch Socket Welded Solid Wedge Gate Valve 800 LB Metal Seat Asme B1.20.1 1/2 Inch Socket Welded Solid Wedge Gate Valve 800 LB Metal Seat Asme B1.20.1
Basic Information
Place of Origin: LISHUI,ZHEJIANG
Brand Name: VERVO
Certification: API/CE/ISO
Model Number: Z61H-800LB
Minimum Order Quantity: 10
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 1 week
Payment Terms: L/C, T/T, Western Union, D/A
Supply Ability: 40000pcs/month
Contact Now
Name: Forged Steel Weld Bonnet Gate Valve Media: Oli,Gas,Water
Standard: API602/BS5352/GOST/JIS/DIN/ISO Pressure: 150LB-800LB,1500LB,2500LB
Power: Manual,Pneumatic,Solenoid,Electrical Actuated Temperature Of Media: Medium Temperature,Normal Temperature,High Temperature,-65°F To 450°F (-54℃ To 232℃)
Size: 1/4"-4",DN8-DN100
High Light:

Socket Welded Solid Wedge Gate Valve 800 LB

,

socket welded gate valve Asme B1.20.1

,

metal seat gate valve Asme B1.20.1

Solid Wedge Gate Valve 800LB 1/2 Inch High Pressure Socket Welded Gate Valve Asme B1.20.1 ISO 9001 Certified Metal Seat



Quick Detail

1/2 Inch Socket Welded Solid Wedge Gate Valve 800 LB Metal Seat Asme B1.20.1 0
Model number Z11Y-800LB-DN15
Item Weld Bonnet Gate Valve
Certification ISO9001,ISO14001,ISO18001,TS,CE,API
Connection form SW
Body material Forged steel ASTM A105N
Purpose Sutiable for Various Industrise
Temperature -29-425




Forged Weld Bonnet Carbon Steel Gate Valve

1/2 Inch Socket Welded Solid Wedge Gate Valve 800 LB Metal Seat Asme B1.20.1 0

• Forged Carbon Steel Gate Valve
• Class 150/300/600/800/900/1500/2500/4500
• Reduced Port/Full Port
• Available in Forged (A105, LF2, F5, F11, F22, A182 F304 (L), F316 (L), F347, F321, F51,F53,F55,F60), Alloy 20, Monel, Inconel, Hastelloy,C95800
• ASME B16.34
• Maximum Pressure 1975 PSI
• Maximum Temperature 850
• Bolted Bonnet/Welded Bonnet/Pressure Seal Bonnet
• API 602 /BS5352/ API 598
• NACE MR0175
• Sizes 1/2” - 4”

Features and benefits

1/2 Inch Socket Welded Solid Wedge Gate Valve 800 LB Metal Seat Asme B1.20.1 2

TWO TYPES:

● This valve is available with an extended body or an integrally reinforcedextended body (IREB).
● Extended body gate valves have a welded or threaded connection and are used for tapping of pressure vessels and header lines for vents, drains or takeoff lines and instrumentation.
● Also available: extended body assemblies for vents, drains, and instrument root valves.



1/2 Inch Socket Welded Solid Wedge Gate Valve 800 LB Metal Seat Asme B1.20.1 3
CL800 Bolt Bonnet (BB)/Welding Bonnet (WB),
Reduce Port (RP)/Full Port (FP), Outside Screw and Yoke (OS&Y), Thread (NPT), Socket Weld (SW), Butt Weld (BW),
Size (NPS) R.P 1/2 3/4 1 1-1/4 1-1/2 2 2-1/2
F.P 3/8 1/2 3/4 1 1-1/4 1-1/2 2
Face To Face L 79 92 111 120 120 140 178
Handwheel Diameter W 100 100 125 160 160 180 200
Height H 165 169 207 230 249 283 333
Flow Port Diameter d 10.3 13.5 18 23 29 36 45
Weight (Kg) B.B 2.2 2.4 4.1 5.5 7.5 10 19
W.B 2.1 2.3 4 5.5 7.3 9.5 18.5
1/2 Inch Socket Welded Solid Wedge Gate Valve 800 LB Metal Seat Asme B1.20.1 3
CL900~CL1500 Bolt Bonnet (BB)/ Welding Bonnet (WB),
Reduce Port (RP)/ Full Port(FP), Outside Screw and Yoke(OS&Y), Thread(NPT), Socket Weld(SW), Butt Weld(BW)
Size (NPS) R.P 1/2 3/4 1 1-1/4 1-1/2 2 2-1/2
  F.P 3/8 1/2 3/4 1 1-1/4 1-1/2 2
Face To Face L 92 111 120 120 140 178
Handwheel Diameter W 100 125 160 160 180 200
Height H 169 207 230 249 283 333
Flow Port Diameter d 10.3 13.5 18 23 29 36
Weight (Kg) B.B 2.4 4.1 6.2 6.2 8.7 12.5
W.B 2.2 4 6 6 8.5 12
1/2 Inch Socket Welded Solid Wedge Gate Valve 800 LB Metal Seat Asme B1.20.1 5
CL2500 Welding Bonnet (WB),
Reduce Port (RP)/Full Port (FP), Outside Screw and Yoke (OS&Y),
Thread (NPT), Socket Weld (SW), Butt Weld (BW)
Size
(NPS)		 R.P 3/8 1/2 3/4 1 1-1/4 1-1/2 2
Face To Face L   120 120 120 140 178 178
Handwheel Diameter W   160 160 160 180 200 200
Height H   230 235 249 283 333 333
Flow Port Diameter d   10.3 13.5 18 23 29 36
Weight
(Kg)		 W.B   6.5 6.5 6.5 9 13 13



Keywords of Solid Wedge Gate Valve 800LB 1/2 Inch High Pressure Socket Welded Gate Valve Asme B1.20.1 ISO 9001 Certified Metal Seat

1/2 Inch Socket Welded Solid Wedge Gate Valve 800 LB Metal Seat Asme B1.20.1 6

High Pressure Gate Valve,Forged Steel WB Gate Valve, Weld Bonnet Gate Valve, A105N Gate Valve, 1 Inch Gate Valve ,Class 800 Gate Valve,API602 Gate Valve, BS5352 Gate Valve, 25mm BB Gate Valve,DN25 Gate Valve,SW End Gate Valve,Full Port Gate Valve,Solid Wedge Gate Valve,Reduce Port Gate Valve
