Extension Stem High Pressure Cryogenic Gate Valve Forged Stainless Steel Gate Valve F316L 2 Inch DN50 2500LB Flanged RF

Basic Information
Place of Origin: LISHUI,ZHEJIANG
Brand Name: VERVO
Certification: API/CE/ISO
Model Number: Z41Y-2500B-DN50
Minimum Order Quantity: 10
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 1 week
Payment Terms: L/C, T/T, Western Union, D/A
Supply Ability: 40000pcs/month
Name: High Pressure Low Temperature Forged Steel Gate Valve Connection: Socket Weld,RF Flange,FNPT,RTJ Flange,BW
Standard: API602/BS5352/GOST/JIS/DIN/ISO Pressure: 150LB-800LB,1500LB,2500LB
Power: Manual,Pneumatic,Solenoid,Electrical Actuated Temperature Of Media: Medium Temperature,Normal Temperature,High Temperature,-65°F To 450°F (-54℃ To 232℃)
Size: 1/4"-4",DN8-DN100

Extension Stem High Pressure Cryogenic Gate Valve Forged Stainless Steel Gate Valve F316L 2 Inch DN50 2500LB Flanged RF

General Introduction:
Extension Stem High Pressure Cryogenic Gate Valve Forged Stainless Steel Gate Valve F316L 2 Inch DN50 2500LB Flanged RF 0
VERVO forged steel valve has the advantages of small volume and compact type. Bolted bonnet, welded bonnet, pressure bonnet, bellow seal bonnet, high/low temperature extended bonnet and ISO 15848 fugitive emission designed valves are available upon different request of services.

Forged Steel Gate Valve
VERVO forged steel gate vales adopts solid gate, renewable seat, rising stem and non-ring hand wheel. It plays the role of pipe opening and closing ultimately through the rotation of the hand wheel to drive the lifting of gate.

Item Forged Steel Cryogenic Gate Valve
Type Gate Valve
Certification ISO9001,ISO14001,ISO18001,CE,TS
Brand VERVO
Model number Z41Y-2500LB-DN50
Port Size 2''
Pressure 2500LB
Temperature -196-300℃
Connection form RF FLANGE
Body material Forged steel F316L
Feature Easy disassembly and assembly



Standards
Extension Stem High Pressure Cryogenic Gate Valve Forged Stainless Steel Gate Valve F316L 2 Inch DN50 2500LB Flanged RF 0
Design & Manufacture
API 602, ISO 15761, ASME B16.34
Face-to-face
VERVO'STD, ASME B16.10
End Dimension
ASME B1.20.1 (NPT)
ASME B16.11 (SW)
ASME B16.25 (BW)
ASME B16.5 (RF, RTJ),
Test & Inspection
API 598
Typical Materials
Body,Bonnet,Disc
A182 F304, F304L, F316, F316L
Stem
F304, F304L, F316, F316L

Extension Stem High Pressure Cryogenic Gate Valve Forged Stainless Steel Gate Valve F316L 2 Inch DN50 2500LB Flanged RF 2
About Us
Extension Stem High Pressure Cryogenic Gate Valve Forged Stainless Steel Gate Valve F316L 2 Inch DN50 2500LB Flanged RF 3
VERVO
is an ISO 9001 certified company specializing in manufacturing industrial valves including ball valves, gate valves, globe valves, check valves, plug valves and butterfly valves in carbon steel, stainless steel, duplex stainless and alloy materials. Our products conform to the latest industry standards in accordance to ANSI, ASME and API.VERVO today has over 10000 square meters of manufacturing facilities. Through its conviction to provide only the finest quality products and services to match the need of our customers, VERVO has now established itself as a serious player in the valve business.
VERVO has sold worldwide in North America, Europe, South America, South Asia, Africa and the Middle East. We consider product quality and customer satisfaction as our highest priority.
We look forward to new customer relationships by providing value, quality, customer service,honesty, integrity and the commitment to maintain product consistency with each and every order.
