| Place of Origin: | LISHUI,ZHEJIANG |
|---|---|
| Brand Name: | VERVO |
| Certification: | API/ISO/CE |
| Model Number: | Q11F-DN32-600LB |
| Minimum Order Quantity: | 1 |
| Packaging Details: | plywood case |
| Delivery Time: | 30 |
| Payment Terms: | T/T, L/C, D/P, Western Union |
| Supply Ability: | 400000 |
| Design Standard: | API608 | Body Material:: | CF8 Stainless Steel |
|---|---|---|---|
| Nominal Diameter: | 1 1/4 Inch 1.25 Inch DN32 | Pressure: | CL600 |
| End Connection.: | Thread FNPT BSPT | Face To Face: | Factory Standard |
| Test And Inspection: | API 598 |
DN32 Casting Steel 2pcs Ball Valve 32mm Full Bore API608 Floating Ball Type Stainless Steel Side Entry RPTFE PTFE Seat
Quick Detail
VERVO floating ball valves are offered in 2 PC side entry, 3 PC side entry or welded body design in a wide range of carbon, stainless steel, duplex stainless steel, alloy and other special materials. VERVO floating ball valves are manufactured according to API 6D or API 608 Design and fire tested per API 6FA and API 607 Standard.
Product Application
Main application:The products are widely used in oil,gas,chemical,electric power metallurgy,lifting,water supply,auto ship manufacturing oil-water road heating system control ,food,pharmaceutical,daily chemical industry ,municipal construction,mechanical equipment,etc.We keep on the concept of credit management, and try our best to givebest serviceto our customers!
| Product description | |
| 1,Product name | DN32 Three piece stainless steel 304 BSPT Threaded ball valve with Quality Testing |
| 2,Size ranging | 1/2"-4" |
| 3,Material option | 304/316 |
| 4,Connection end options | Thread, Flange, Welded, Clamp, etc |
| 5,Working pressure | 1000psi, PN63 |
| 6,Applicable temperature | -20-210 degree C |
| 7,Applicable medium | Water, Oil, Gas, etc |
| 8,End connection | Female Threded as photo |
| 9,MOQ | 100PCs |
| 10,Capacity to produce | 100,000,00 PCs per week |
| 11,Packaging | Inner CTN, outside ply-wooden cases |
| 12,Price term: | EXW, FOB, CIF, CFR |
| 13, Options | with Locking or not, with the Mounting top or not |
| 14,Standard | CE,ISO9001,API |
Keywords of DN32 Casting Steel 3pcs Ball Valve 32mm Full Bore API608 Floating Ball Type Stainless Steel Side Entry RPTFE PTFE Seat
DN32 Ball Valve,Casting Ball Valve,3 Piece Ball Valve,Soft Seal Ball Valve,Three Piece Ball Valve,Casting steel Stainless Steel Ball Valve,Metal to Metal Seat Ball Valve
